Core configuration

Battery safety The high-capacity battery assembly is arranged reasonably and meets the safety requirements of GB38031. In the event of collision or compression, there will be no shell rupture, fire or explosion, ensuring the personal safety of drivers and passengers.
	Motor, electrical control The highest efficiency of the motor is 95%, with a peak torque of 2600Nm. The protection level of key components such as the three electrical systems meets the IP67 requirement, ensuring reliable operation in rainy and snowy weather and water related conditions.
Transmission Independently developed efficient two speed gearbox; Aggressive shifting and smooth shifting.
	Thermal management Internationally renowned brands can easily cope with harsh working conditions ranging from -30 ℃ to 50 ℃.

Product selling points

Braking energy recovery technology Innovation leads the energy recovery technology of electric loaders, utilizing the braking process to convert kinetic energy into electrical energy storage, reducing energy consumption of electric loaders by 18%. Brake priority Avoid brake disc wear caused by power during braking. Increase braking energy recovery and reduce energy consumption. To avoid accidents caused by driver's misoperation. In case of abnormal vehicle signals, braking priority is safer. Intelligent start stop technology Breaking through the creation of intelligent start stop technology, adopting the recognition of driver intentions, and stopping the pump motor when the vehicle is in a non working state. Solved the problem of standby energy consumption loss, resulting in a 5% reduction in electrical installation energy consumption.

Convenient charging Standard interface, compatible with all manufacturers of DC piles in the market

Super strong adaptability, capable of fast charging in extremely cold and hot environments

Parameter category	Parameter values
battery level	423/350kWh*1
Scope of usage environment	-35℃-60℃

Extreme charging: Theoretical charging time of charging stations above 300kw<1.5 hours *²

Charging station power	Charging time
240kW charging station	423kWh About 90 minutes 350kWh About 70 minutes
300kW charging station	423kWh About 70 minutes 350kWh About 55 minutes

Double gun fast charging, maximum charging current 400A

*1. The 6-ton model can be equipped with 423/350kWh batteries. *2. Under standard testing conditions, it takes 20% -100% of the battery to charge with two guns. The actual charging time is affected by factors such as the power of the charging station, ambient temperature, and altitude.

• Superior sealing performance, improved by 10% compared to fuel loaders
• Comfortable to drive and ride, with noise levels as low as 68dB
• Adopting silicone oil suspension technology, high-end configuration in the industry, and superior vibration isolation performance in the cab
• New energy electric drive systems reduce vibration by 30% compared to traditional fuel vehicles
• High power heating and cooling air conditioners can fully meet the heating and cooling needs under ambient temperatures of -30 ℃ -50 ℃
• Large size full HD glass, panoramic large space, and wide field of view

High definition display, touch operation One screen overview of the entire machine information Real time reminder of monitoring information	Easy to operate, flexible and fast Multifunctional integrated handle One click gear shift, fingertip direction change	Integrated control, intelligent and convenient One click start stop Graphical integrated soft keys

Applicable working conditions

Mainly suitable for working conditions such as steel mills, power plants, coal plants, ports, mixing plants, etc
